ST5+

The X-LAB ST5+ brings X-LAB engineering to modern urban mobility. Powered by an integrated electric system and built on a refined aluminum platform, the ST5+ delivers smooth acceleration, confident handling, and the comfort needed for everyday riding. Designed for riders who want more from their city bike, the ST5+ makes commuting faster, cleaner, and far more enjoyable. From daily travel to spontaneous detours, the ST5+ transforms the way you move through the city.

• Suggested Use
  • City/Bike Path, Commuting
• Frame
  • XDS X6 Alloy Frame, UDH Compatible
• Fork
  • XDS Suspension Fork, Coil Spring, 80mm Travel, 110x15mm Thru-axle
• Motor
  • XDS Mid-drive X800 Motor, 250 Watt Continuous Rated Power, 470 Watt Peak Power, 95Nm Peak Torque, Dual-sided Torque Sensor
• Battery
  • XDS Rechargeable Li-ion Battery, 619Wh, LG Battery Cells, 3A Charger (0-100% 5hr)
• Handlebars
  • Branta Alloy Integrated, w/ Display & Front Light, 680mm width, 90mm Length, 6 Degree Rise, 15 Degree Backsweep
• Brakes
  • Branta EC4D Hydraulic E-Bike Brake, w/ Cutoff Switch, 3 Finger Lever, 4 Piston Caliper
• Rear Derailleur
  • Shimano Cues RD-U4000, 9-Speed
• Shift Levers
  • Shimano Cues 9-Speed
• Crankset
  • Branta Alloy Crankset, 46T, Narrow-wide Teeth
• Chain
  • KMC E-GLIDE-S
• Cassette
  • Shimano CS-LG300 11-46T, 9-Speed
• Wheels
  • Branta Alloy E-Bike Wheelset
• Tires
  • CST CTC-06, 27.5’’x2.4, 30TPI, w/ Reflective Stripe
    • Max Tire Clearance: 2.4"
• Saddle
  • Branta C301
• Seatpost
  • XDS 31.6mm Alloy Seatpost , 350mm Length
• Extras

  • Apple Find My Anti-Theft Technology, Bluetooth, OTA Updates
  • UL2271 and UL2849 Certified, Ingress Ratings: Complete Bike IP54, Battery IPX7, Motor and Other Electronics IPX6
  • Ride up to 75 miles on a Single Charge
  • Pedal-assist and Throttle, Class 2 20mph (Unlock to Class 3 via the X-Lab Bikes Mobile App)
  • Quad Lock Mount
  • MIK-HD Rear Rack
  • Integrated F+R Lights (+ Brake Lights)
• Weight
  • 24.76 kg / 54.58 lbs (Size L)
